USED DOOSAN PUMA GT-2600M 3-AXIS CNC TURNING CENTER (2018)

SWING OVER BED..................... 28.3"
SWING OVER CROSS .................. 18.1"
MAX. TURNING DIAMETER ............. 18.94"
TURNING LENGTH .................... 50.2
CHUCK SIZE ........................ 12"
SPINDLE NOSE ...................... A2-11
SPINDLE THROUGH HOLE DIA. ......... 4.53"
MAXIMUM BAR CAPACITY .............. 4.0”
X-AXIS TRAVEL ..................... 10.24"
Z-AXIS TRAVEL ..................... 53.15"
RAPID TRAVERSE RATE X/Z ….......... 945/1181 IPM
MAX. SPINDLE SPEED, MAIN .......... 2800 RPM
MAIN SPINDLE MOTOR ................ 29.5 HP
NO. OF TOOL STATIONS .............. 12
TAILSTOCK TRAVEL .................. 45.3"
QUILL DIAMETER .................... 3.9"
QUILL TRAVEL ...................... 3.9"
TAILSTOCK TAPER ................... MT#5
MACHINE DIMENSIONS ................ 184” x 94” x 83”
APPROX. MACHINE WEIGHT ............ 12125
POWER REQUIREMENTS................. 220 V, 3 PH, 60 HZ, 40 KVa
